Phoenix 12/1200 VE.Direct
Pure-sine inverter, 1000W continuous. 12 V DC input — the 12/ in the model number is the input voltage.
Open in Crimp →
Victron Phoenix Inverter 12/1200 · 4 terminals
01 — Reference run
A sizing result with its assumptions attached.
Conductor95 mm²3/0 AWG
Fuse300 Apositive run
Voltage drop0.8%3 m one way
Design current92 A12 V system
The Crimp engine applies its ordinary continuous-load headroom, voltage-drop budget, terminal clamp, and standard fuse ladder. The 3 m one-way run is a stated reference, not a universal installation prescription.
02 — Catalog specification
The part the engine actually sees.
- Compatible systems
- 12 V
- Rated power
- 1,000 W
- Continuous draw
- 92 A
- Surge current
- 201 A
- Canvas footprint
- 220 × 120 px
Terminal map
| Terminal | Polarity | Direction | Rating |
|---|---|---|---|
| DC + | positive | input | 150 A |
| DC − | negative | input | 150 A |
| AC L | neutral | output | 8 A |
| AC N | neutral | output | 8 A |
03 — Supporting parts
What belongs around it.
- 6 m total of 95 mm² (3/0 AWG) marine cable
- Four 95 mm² cable lugs matched to the equipment studs
- 300 A fuse and holder on the positive run
- Heat-shrink, strain relief, and terminal boots sized to the cable
See what it changes in your system
With JavaScript enabled, describe your existing boat, van, or off-grid system here. The model supplies topology; Crimp's engine computes the attachment, resized runs, checks, and supporting basket.
