Engine 29HP — Yanmar 3YM30 wiring diagram

Original Yanmar 3YM30, distinct from 3YM30AE. Manufacturer service data specifies a 1.4 kW starter and 60 A internally regulated alternator (80 A optional). The 250 A cranking and 350 A surge are planning estimates; identify the fitted panel and charging equipment.

Continuous draw
250 A
Rated output
60 A
Surge current
350 A
Units

Wiring diagram

How the 3YM30 29HP is wired.

Open this example in Crimp to use your own parts and cable lengths. Review the assumptions and installation notes as you adapt the circuit.

Engine 29HP — Yanmar 3YM30 wiring example with 4 components: 3YM30 29HP, Starter bank, 30 A DC/DC charger, House bank. 7 cable connections. Crossings are not junctions.3YM30 29HP Alt B+ to Starter bank +: 25 mm² · 80 A fuse, 3 m one way. 3YM30 29HP Block GND to Starter bank −: 120 mm², 3 m one way. Starter bank + to 3YM30 29HP Starter: 120 mm² · 350 A fuse, 3 m one way. Starter bank + to 30 A DC/DC charger IN +: 10 mm² · 50 A fuse, 3 m one way. Starter bank − to 30 A DC/DC charger IN −: 10 mm², 3 m one way. 30 A DC/DC charger OUT + to House bank +: 10 mm² · 40 A fuse, 3 m one way. 30 A DC/DC charger OUT − to House bank −: 10 mm², 3 m one way3YM30 29HP Alt B+ to Starter bank +: 25 mm² · 80 A fuse, 3 m one way3YM30 29HP Block GND to Starter bank −: 120 mm², 3 m one wayStarter bank + to 3YM30 29HP Starter: 120 mm² · 350 A fuse, 3 m one wayStarter bank + to 30 A DC/DC charger IN +: 10 mm² · 50 A fuse, 3 m one wayStarter bank − to 30 A DC/DC charger IN −: 10 mm², 3 m one way30 A DC/DC charger OUT + to House bank +: 10 mm² · 40 A fuse, 3 m one way30 A DC/DC charger OUT − to House bank −: 10 mm², 3 m one wayEngine 29HP — Yanmar 3YM30. The starter input and alternator output connect to the same starter bank. The DC/DC charger limits charging of the separate house bank. This is the main DC power arrangement only: retain the engine's original controls, harness, bonding and alternator regulation. Verify cranking capacity, alternator reserve and manufacturer protection requirements.3YM30 29HPStarterStarterAlt B+Block GNDBlock GND12 V 200 Ah placeholder starter bank. 200 Ah placeholder bank. The 384 A discharge and 100 A charging envelopes are example assumptions, not specifications inferred from capacity. Replace them with actual battery, cranking and alternator-regulation evidence. Protect each battery-fed positive branch as required by its circuit.Starter bank++−−12 V 30 A DC/DC charging allowance. 30 A output, 34 A input and 90% efficiency are explicit planning assumptions for a 12/12 V charger. Choose the actual charger, set its input limit to the alternator's available continuous reserve, and follow its ignition/enable, fuse and cable requirements.30 A DC/DC chargerIN +IN +IN −IN −OUT +OUT +OUT −OUT −12 V 200 Ah placeholder house bank. 200 Ah placeholder bank accepting 30 A in this example. Verify the actual battery/BMS limits and configure the charger's battery profile before use.House bank++−−120 mm²120 mm² · 350 A fuse10 mm²10 mm² · 40 A fuse10 mm²
Engine 29HP — Yanmar 3YM30 wiring example with 4 components: 3YM30 29HP, Starter bank, 30 A DC/DC charger, House bank. 7 cable connections. Crossings are not junctions.Red = positive · dark = return · dashed = signal. Wire sizes and fuse ratings are example values; use the equipment instructions and actual installation lengths.
Edit this wiring example

Cable sizing for this example

Use the diagram as a starting point for your installation. Replace the example equipment and cable lengths with your own, and check the connections against your exact model's instructions.

3 m one way

12 V system

Wire
120 mm² · 4/0 AWG
Example fuse
350 A
Cranking current
250 A
Voltage drop
1.9%

Sized against ABYC E-11. The cranking current is what the starter draws. ABYC E-11 doesn't require a fuse on a cranking-motor conductor, so the fuse shown is the usual cranking-rated (Class T) choice, sized to hold the crank without nuisance tripping — it isn't there to protect the wire. The length is one way; voltage drop includes an equal-length return.

Run-length and manufacturer assumptions

The editable example uses 3.048 m (10 ft) runs unless a shorter run is stated. Metric overviews round these to 3 m. Adapt the parts and lengths to your installation before choosing cable and protection.

Supporting parts

  1. 6.1 m total of 120 mm² (4/0 AWG) marine cable
  2. Terminations for 120 mm² cable, matched to the equipment's screw terminals, leads or studs
  3. 350 A cranking-rated (Class T) fuse at the battery
  4. Heat-shrink, strain relief and terminal boots sized to the cable

Check stud sizes, fuse type, run length and how warm the space gets against the gear you actually have before you order.

Installation notes

Before you install.

Open a question for model-specific guidance and sources.

Verified against the manufacturer's documentation (rev. 0BYMM-G00100 \u2014 third edition, November 2006), checked 2026-10-01. Manufacturer documentation →

Engine and edition

This is the original 1.115 L 3YM30 covered by the 3YM30/3YM20/2YM15 service manual, not the later 3YM30AE. The standard alternator is the internally regulated Hitachi LR160-741, 12 V/60 A; the manual also documents an optional 80 A alternator. Identify the fitted alternator before using the charging estimate.

What the terminals mean

`Starter` represents the high-current starter supply, `Alt B+` the alternator charging output, and `Block GND` the intended negative return on an earth-return installation. They are functional drawing ports, not three interchangeable physical studs. Trace any factory link between alternator B+ and the starter battery stud before changing it; do not duplicate or remove that link without accounting for the original harness.

Controls and protection

The electrical chapter distinguishes the original instrument panel from a newer panel with a 3 A instrument fuse. The engine harness includes the starter relay, oil-pressure and coolant-temperature warnings, charge warning/excitation circuit and electric stop solenoid. Match the panel and harness drawing to the engine serial number; neither the warning lamp nor the stop wire is a charging output.

Checks and model limits

The Hitachi S114-817A starter is rated 1.4 kW. Its service test specifies 250 A at 8.4 V under a defined load; that is not a universal cranking current measured at a 12 V battery. The catalog 250 A starting draw and 350 A surge remain planning assumptions. Check actual cold cranking voltage, cable losses and the starter battery before relying on them. Keep the battery connected while the alternator runs; a lithium installation needs charge-current and disconnect coordination beyond this three-terminal model.

Source: manufacturer document — electrical diagrams printed pp. 183–185 (PDF 204–206), starter p. 186 (PDF 207), alternator pp. 189–192 (PDF 210–213). Legacy copies hosted outside the manufacturer site are manufacturer-authored archive documents; the review date does not make them current installation instructions.

Fit check

Connect it to the rest of your system.

Describe your setup to draft a system with 3YM30 connected. Review the selected parts and cable lengths, then edit the diagram in Crimp.

The model only picks parts and draws the connections. Every wire size and fuse rating still comes from Crimp's own sizing, never from the model.

Enable JavaScript to describe your system.

Technical reference

Specifications and terminal map.

Check the model, ratings and connection points against your own unit before choosing installation hardware.

Catalog specification

Original Yanmar 3YM30, distinct from 3YM30AE. Manufacturer service data specifies a 1.4 kW starter and 60 A internally regulated alternator (80 A optional). The 250 A cranking and 350 A surge are planning estimates; identify the fitted panel and charging equipment.

Continuous draw
250 A
Rated output
60 A
Surge current
350 A

Terminal map

Catalog connection points, current direction and planning limits. Check the manufacturer's pinout and connector ratings before installation.

Starter

positive · input

500 A

Alt B+

positive · output

200 A

Block GND

ground · bidi

500 A
Sources and sizing method

Equipment specifications. Model details, ratings and terminal roles come from the catalog. Check your unit’s label and current manufacturer documentation for its exact revision.

Example sizing. Sized against ABYC E-11. Boats built to UK or EU rules answer to ISO 13297 — check these figures against it before you build. Results use the example current and run length shown above. Set your actual equipment, lengths and installation conditions in Crimp before choosing hardware.
