CrimpAnderson SB175 Connector
Genderless 175A power connector. Common for shore-style trailer hookups.
Open in Crimp →
How the SB175 is wired
The run drawn here is the reference topology for this part. Sized against ABYC E-11. Boats built to UK or EU rules answer to ISO 13297 — check these figures against it before you build. Confirm your own run length, routing and terminations before ordering — open this part in the designer to size it against your actual system.
What size cable and fuse does the SB175 need?
There is no standalone feed to size here: this part either has no positive current-carrying terminal or declares no continuous draw or rated output of its own, so a lone cable number would really be its terminal rating. Its cables are sized by the circuits they serve — use the terminal map and the complete-system fit check.
Anderson SB175 Connector specifications and terminal map
Terminal map
| Terminal | Polarity | Direction | Rating |
|---|---|---|---|
| + | positive | bidi | 175 A |
| − | negative | bidi | 175 A |
| + | positive | bidi | 175 A |
| − | negative | bidi | 175 A |
