X4 012301W
OceanLED X4 Ultra White Underwater Light wiring diagram
Single-colour X4 underwater light with 0.8 A at 12 V or 0.4 A at 24 V and 10 W maximum nominal power. The manual specifies a separate 1.25 A fuse for each light. Red is positive and black negative; the RGB/DMX wiring diagrams do not apply to this white version.
- Nominal voltage
- 12 V
- Compatible systems
- 12 V / 24 V
- Rated power
- 10 W
Wiring diagram
How the X4 Ultra White is wired.
Open this example in Crimp to use your own parts and cable lengths. Review the assumptions and installation notes as you adapt the circuit.
Exact manufacturer fuse is 1.25 A per X4. Supply wiring and switching for multiple lights must account for their combined load. Manufacturer installation manual
Edit this wiring exampleCable sizing for this example
Use the diagram as a starting point for your installation. Replace the example equipment and cable lengths with your own, and check the connections against your exact model's instructions.
10 ft one way
12 V system
- Wire
- 16 AWG · 1.5 mm²
- Example fuse
- 1.25 A
- Design current
- 0.8 A
- Voltage drop
- 0.5%
Sized against ABYC E-11. The design current is the part's continuous draw. The length is one way; voltage drop includes an equal-length return.
Run-length and manufacturer assumptions
The editable example uses 3.048 m (10 ft) runs unless a shorter run is stated. Metric overviews round these to 3 m. Adapt the parts and lengths to your installation before choosing cable and protection.
Exact manufacturer fuse is 1.25 A per X4. Supply wiring and switching for multiple lights must account for their combined load. Manufacturer installation manual
Supporting parts
- 20 ft total of 16 AWG (1.5 mm²) marine cable
- Terminations for 16 AWG cable, matched to the equipment's screw terminals, leads or studs
- 1.25 A fuse and holder on the positive run
- Heat-shrink, strain relief and terminal boots sized to the cable
Check stud sizes, fuse type, run length and how warm the space gets against the gear you actually have before you order.
Installation notes
Before you install.
Open a question for model-specific guidance and sources.
Verified against the manufacturer's documentation (rev. MAN-000045 Rev 1), checked 2026-10-01. Manufacturer documentation →
Choose the single-colour X4 wiring
This entry covers the Ultra White X4, not the larger X8/X16 or an RGBW installation. The manual gives 0.8 A at 12 V and 0.4 A at 24 V, with 10 W maximum nominal consumption. The 12 W figure in the adjacent table column is a power-supply sizing allowance that includes reserve; it is not the light’s specified battery load. The catalog’s 0.8 A planning value is for nominal 12 V operation.
Fuse each light and seal every joint
For this single-colour version, connect red to switched positive and black to negative. Fit the specified 1.25 A fuse for each light; do not replace several individual fuses with one oversized branch fuse. Select the common supply and switch/relay for the combined load and route length using the manual’s cable tables. Keep the supplied cable and all joins supported and watertight, with the seal enclosing the outer sheath. Bare cable ends must never be left in bilge water, even while installation is unfinished.
Prepare the underwater mounting surface
Use a clean flat mounting surface and follow the hull-material instructions, including the appropriate isolation arrangement for conductive hulls. The manual illustrates mounting with the top of the light approximately 4–8 inches below the waterline and typical 2–3 foot spacing. Drill and seal the cable penetration as specified. Apply an unbroken marine-sealant barrier around the light and cable entrance; tighten the mounting screws by hand as directed rather than crushing the fitting with power tools.
Test before launching and inspect afterwards
Check polarity, individual fuses and switching before entering the water. Disconnect power before connecting or disconnecting light wiring. After launching, inspect the penetration and surrounding area immediately for leaks and repeat checks rather than leaving a new installation unattended. Keep the lens clean using the permitted methods; abrasive cleaning can damage its coating. Uneven apparent brightness can also result from depth, water clarity and bottom reflection, so verify wiring and mounting conditions before assuming the LED unit has failed.
Manual and scope
OceanLED installation manual, MAN-000045 Rev 1; p. 4 consumption/fuse table, pp. 5–10 placement and mounting, single-colour wiring p. 11, cable tables pp. 23–26. The original PDF is retained in the marine source ledger. The drawing represents the identified electrical interfaces; it does not simulate the equipment’s mechanical performance, radio signals or fluid system. Unpublished connector ampacity and startup current remain unspecified.
Technical reference
Specifications and terminal map.
Check the model, ratings and connection points against your own unit before choosing installation hardware.
Catalog specification
Single-colour X4 underwater light with 0.8 A at 12 V or 0.4 A at 24 V and 10 W maximum nominal power. The manual specifies a separate 1.25 A fuse for each light. Red is positive and black negative; the RGB/DMX wiring diagrams do not apply to this white version.
- Nominal voltage
- 12 V
- Compatible systems
- 12 V / 24 V
- Rated power
- 10 W
- Continuous draw
- 0.8 A
Terminal map
Catalog connection points, current direction and planning limits. Check the manufacturer's pinout and connector ratings before installation.
Red +
positive · input
Black −
negative · input
A dash means a current rating is not specified here.
Sources and sizing method
Equipment specifications. Model details, ratings and terminal roles come from the catalog. Check your unit’s label and current manufacturer documentation for its exact revision.
Example sizing. Sized against ABYC E-11 — the US reference, and what Transport Canada accepts as an alternative to TP 1332 for pleasure craft under 24 m. Results use the example current and run length shown above. Set your actual equipment, lengths and installation conditions in Crimp before choosing hardware.
