EFOY 80 Fuel Cell (12 V configuration) connections

Review the EFOY 80 Fuel Cell (12 V configuration) connections, setup and installation requirements. This overview does not calculate cable or protection sizes.

Nominal voltage
12 V
Compatible systems
12 V
Rated power
40 W

Connection overview

EFOY 80 connections.

See how this component fits into a system. Use the manufacturer’s installation instructions for the complete connections.

EFOY 80 Fuel Cell (12 V configuration) connection overview with 1 components: EFOY 80. 0 cable connections. Crossings are not junctions.EFOY 80 Fuel Cell (12 V configuration). EFOY requires separate POWER and SENSE pairs at the battery, with 20 A and 2 A protection respectively. Follow the complete four-wire harness, exhaust, fuel and ventilation installation. A two-wire charging example would omit mandatory voltage sensing. Connection overview only. Cable lengths are placeholders; use the complete manufacturer diagram to select conductors and protection. No automatic fuse or cable-size recommendation is supplied by this example.EFOY 80
EFOY 80 Fuel Cell (12 V configuration) connection overview with 1 components: EFOY 80. 0 cable connections. Crossings are not junctions.EFOY requires separate POWER and SENSE pairs at the battery, with 20 A and 2 A protection respectively. Follow the complete four-wire harness, exhaust, fuel and ventilation installation. A two-wire charging example would omit mandatory voltage sensing. Connection overview only. Cable lengths are placeholders; use the complete manufacturer diagram to select conductors and protection. No automatic fuse or cable-size recommendation is supplied by this example.

12 V rated-output example: 40 W cap and 3.8 A peak at 10.5 V, no alternator derating. Manual PDF 29 requires 20 A power fuse AND separate 2 A sense fuse; 4 mm² power extension <=10 m. A two-wire drawing alone is incomplete. Exhaust, air supply, fuel and frost-protection connection remain essential. Manufacturer installation manual

Edit this connection overview

Installation notes

Before you install.

Open a question for model-specific guidance and sources.

Verified against the manufacturer's documentation (rev. EFOY 80/150/Pro 2800 data sheet, March 2022), checked 2026-10-01. Manufacturer documentation →

Rated power and the selected voltage

This entry represents EFOY 80 configured for a 12 V battery. The unit supports other settings, but a drawing must use the configured voltage consistently. Its maximum rated output is 40 W; the published 3.8 A is a peak current at 10.5 V, not 3.8 A at every battery voltage. Rated-output simulation is an operating point, not guaranteed daily generation. The data sheet permits declining output with age and specifies minimum bank capacities of 40 Ah lead-acid or 20 Ah lithium. See ratings and aging qualification, PDF p. 1.

Four battery conductors are required

The charging harness has separate POWER+ and POWER− conductors and a SENSE+ / SENSE− pair. The sense wires measure voltage at the battery so cable drop does not mislead charging control; they do not carry the main output. Preserve both circuits and polarity. Fit the documented 20 A power fuse and 2 A sense fuse near the battery. Those fuse ratings do not describe fuel-cell output current. See battery connection, PDF p. 29.

Cable and installation space

Use at least 4 mm² power conductors for extensions up to 10 m and 6 mm² for 10–15 m, following the manual's extension arrangement. The sensor pair is 0.75 mm² in the supplied harness. This is a ventilated fuel-burning appliance: provide incoming air, a separate exhaust-heat outlet and the supplied exhaust-gas hose led outdoors. Keep the exhaust-gas route unblocked and draining as specified. See air and outlet requirements, PDF p. 13 and exhaust routing, PDF p. 23.

Configure charging and preserve frost protection

Select the battery type and permitted charge settings, connect a genuine EFOY fuel cartridge, and verify measured voltage before automatic charging. Temperature, battery demand and aging change output. Sleep mode still supports battery protection and automatic antifreeze behavior. Below about 3 °C, keeping a suitable battery connection and fuel supply available is part of the manufacturer's frost protection procedure; an isolator that removes power defeats it. See frost-protection notice, PDF p. 1.

Technical reference

Specifications and terminal map.

Check the model, ratings and connection points against your own unit before choosing installation hardware.

Catalog specification

Methanol fuel-cell battery charger, 40 W rated maximum and 3.8 A peak at 10.5 V. Rated-output operation depends on temperature, age and charge control; power and sense leads are both required.

Nominal voltage
12 V
Compatible systems
12 V
Rated power
40 W
Rated output
3.8 A

Terminal map

Catalog connection points, current direction and planning limits. Check the manufacturer's pinout and connector ratings before installation.

POWER +

positive · output

—

POWER −

negative · output

—

SENSE +

signal · bidi

—

SENSE −

signal · bidi

—

A dash means a current rating is not specified here.

Sources and sizing method

Equipment specifications. Model details, ratings and terminal roles come from the catalog. Check your unit’s label and current manufacturer documentation for its exact revision.

Connection overview. This diagram explains the connection arrangement; it does not calculate cable sizes or protection for the installation. Follow the manufacturer’s complete wiring and protection instructions.
