Charger

Victron Orion-Tr Smart 12/12-30

Isolated 30A DC-DC charger from start to house battery. Engine-run detection from input voltage; Victron's manual calls for a 60A fuse on the input side.

The reference run on this page is 3 m one way, sized against ABYC E-11. Your own run will differ, and the canvas sizes that one.

Wiring diagram

How the Orion 30A is wired.

The drawing shows where the feed, the return and the fuse land on this part. The starter uses the same reference circuit and sizing assumptions. Read the installation notes for manufacturer requirements before adapting the runs.

Victron Orion-Tr Smart 12/12-30 wiring diagram, 10 mm² (8 AWG) positive feed protected by a 40 A fuse and a matching negative return between the 12 V battery bank and the unit, plus IN +, IN −.
Open starter in Crimp

Build it out

Build the system it goes in.

Open the canvas with Orion-Tr Smart 12/12-30 already placed, then add your batteries, charging, distribution and loads around it.

Every cable you draw there is sized against ABYC E-11, from the same tables as the reference on this page.

Technical reference

Specs, terminals and the parts around them.

The catalog facts for this part, which terminal takes what, and the hardware you'll want around it. Check the nameplate on your own unit before you order.

Catalog specification

Rated output
30 A
Planning charge current
28 A

3 m reference run

12 V system

Wire
10 mm² · 8 AWG
Fuse
40 A
Design current
30 A
Voltage drop
2.7%

Sized against ABYC E-11. Boats built to UK or EU rules answer to ISO 13297 — check these figures against it before you build. The design current is the unit's rated output. The length is one way; voltage drop includes an equal-length return. The shared starter uses 3.048 m (10 ft) runs unless a shorter run is stated. These are example assumptions for you to adapt to your own installation.

Supporting parts

  1. 6 m total of 10 mm² (8 AWG) marine cable
  2. Terminations for 10 mm² cable, matched to the equipment's screw terminals, leads or studs
  3. 40 A fuse and holder on the positive run
  4. Heat-shrink, strain relief and terminal boots sized to the cable

Check stud sizes, fuse type, run length and how warm the space gets against the gear you actually have before you order.

Terminal map

Catalog connection points, current direction and planning limits. Check the manufacturer's pinout and connector ratings before installation.

IN +

in-pos

positive · input

60 A

IN −

in-neg

negative · input

60 A

OUT +

out-pos

positive · output

30 A

OUT −

out-neg

negative · output

30 A

Field notes

How it actually goes in.

What we've read and heard about installing this exact part. These are notes, kept apart from the numbers Crimp works out.

Which Orion-Tr Smart 12/12-30 is this?

This is the isolated Orion-Tr Smart 12/12-30A (360 W), Victron part ORI121236120, the model most "Orion TR Smart 30A wiring diagram" searches mean. Victron also sells a non-isolated 12/12-30 that shares one negative between input and output; this page models the isolated one, whose input and output returns are separate. The product family page rates it at 30 A continuous at 40 °C, a 40 A peak for 10 seconds, about 87 % efficiency and a 10–17 V input.

How is the Orion-Tr Smart 12/12-30 wired?

IN + comes from the starter battery through a fuse at that battery; OUT + charges the house or leisure battery through a fuse at the house battery. IN − and OUT − are two separate returns on this isolated model, one to each bank. Victron's manual calls for a 60 A fuse on the input side, and the installation section carries the full cable-and-fuse table by run length; the screw terminals accept up to 16 mm² (6 AWG). Those fuses protect the cable, and belong at the battery end of each run.

The technical reference above sizes the example run with Crimp's engine from the catalog's terminal ratings, and the starter lets you change the lengths. The manual's table is the floor.

What should I bear in mind with the Orion-Tr Smart 12/12-30?

  • Heat is the defining constraint of this model. At 87 % efficiency roughly an eighth of the throughput becomes heat, and the datasheet rates the 30 A only up to 40 °C, derating about 3 % per degree above it. A closed locker or an engine bay in summer means less than 30 A. Mount it fins-vertical with air moving past; IP43 only applies with the terminals pointing down.
  • Engine detection reads the input voltage. Smart alternators on Euro 5 and Euro 6 vehicles drop the starter side below the detection threshold once that battery is full, and the charger stops. The manual's engine shutdown detection section describes the override from an ignition-switched or D+ feed on the remote connector. Turning detection off in VictronConnect leaves only the input lockout voltage to protect the starter battery.
  • The alternator sees more than 30 A. Output current times output voltage, divided by efficiency and the lower input voltage, is what the starter side supplies, so the input cable, its fuse and the alternator's spare capacity are all budgeted above the nameplate.
  • VictronConnect does not show current. The Orion-Tr Smart range has no current sensor and no VE.Direct port; the non-isolated datasheet prints both as notes. A shunt on the house bank is how you see the amps.
  • Units can be paralleled, without limit per the datasheet, which is how installers get past 30 A without moving to a different product line.

What do owners and installers say about the Orion-Tr Smart 12/12-30?

  • "It gets hot and folds back." The recurring report is a unit that delivers its 30 A cold and settles to roughly 20–25 A once the case is hot in an enclosed compartment; a fan over the fins or relocating it into moving air restores the output. See this thread, this one and the T6 forum. Victron's answer in those threads is that the derating is by design and the fix is airflow.
  • Smart alternators stop it charging. Owners of Fiat Ducato, VW Transporter and Ford Transit vans describe charging that cuts out under "engine shutdown detected"; the fix agreed in this thread and on MotorhomeFun is the ignition or D+ feed to the remote connector, not disabling detection.
  • Fuse placement is asked and answered often. The isolated fuse placement thread and the fusing thread settle on a fuse at each battery, sized for the cable.
  • New builds are steered to the Orion XS. Installers and resellers now recommend the XS 12/12-50 where isolation is not required, for its efficiency, size and current readout; see this comparison and this Victron Community thread. The isolated Orion-Tr Smart remains the pick when the banks must not share a negative.

What belongs around the Orion-Tr Smart 12/12-30?

Verified against the manufacturer's documentation (rev. 14 — 02/2026), checked 2026-09-11. Manufacturer documentation →

Method & provenance

What is known, assumed and computed.

The manufacturer publishes some of these numbers and Crimp works out the rest. It's worth knowing which is which.

From the maker

What the catalog says

Manufacturer, model, ratings and which terminal does what come from the catalog. A newer revision, or the nameplate on the unit in your hand, can say something different — when it does, the nameplate wins.

ABYC E-11

What Crimp worked out

Sized against ABYC E-11. Boats built to UK or EU rules answer to ISO 13297 — check these figures against it before you build. The run length and the current above are what drive the result. Crimp doesn't know how warm your space gets; draw the cable inside an engine-bay zone on the canvas and it sizes for the heat.
