Dometic CFX3 35 wiring diagram

The CFX3 35 has 36 L total volume and accepts 12/24 V DC or 100–240 V AC. Its table rates DC current at 7.5 A on 12 V and 3.3 A on 24 V. Do not borrow the CFX3 25, 45 or dual-zone model currents from adjacent columns. Daily energy depends on ambient temperature, setpoint and use; the catalog operating-hours assumption is separate from the current rating.

`+` and `−` represent the DC inlet through the supplied lead. Keep the fused DC plug: the connection instructions explicitly prohibit removing it. The device also has separate DC and AC fuse holders; replace a failed fuse with the same type and rating as the fitted original. Check the label and cable supplied with the regional unit rather than inferring fuse size from 7.5 A running current.

The 12 V low/medium/high cut-out settings are 10.1/11.2/11.8 V, with restart at 11.4/12.2/12.6 V. For 24 V they are 21.5/24.1/24.6 V, restarting at 23.0/25.3/26.2 V. Select protection for the battery being used, especially when starting reserve matters. Low setting is not a substitute for a battery-management system.

Keep cooling vents clear and measure voltage at the inlet during compressor operation if a low-voltage alert appears. A thin extension or poor socket can produce a fault even with adequate battery voltage. The manual covers settings from −22°C to +10°C; freezing use is a different energy case from refrigeration. The drawing omits AC operation, USB charging, wireless control and the compressor duty cycle, so an energy budget should be checked against the installed unit.

Source: manufacturer document — battery-protection figure p. 11; power connection pp. 26–29; fuse replacement p. 34; CFX3 35 table p. 40 (printed/PDF).
